Engine Cutaway Provides Unique View

YOUNGSTOWN AIR RESERVE STATION, Ohio — The 910th Maintenance Squadron has a working cutaway of a C-130 aircraft engine. The model is used not only for training, but also to show the average person the inner-workings of a turboprop aircraft engine. U.S. Air Force photo/Tech. Sgt. Dennis Kilker Jr.
